| 写真 | モデル | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
|---|---|---|---|---|---|---|---|---|---|---|
 |
Basic 32-8SN | 32 | 4 | 5.5 | 8 | 115/230 | 50/60 | 245/190/135 | 180 | G2 |
 |
Basic 32-8SF | 32 | 4 | 5.5 | 8 | 115/230 | 50/60 | 245/190/135 | 180 | G2 |
 |
Basic 15-12S | 15 | 2 | 9.5 | 12 | 115/230 | 50/60 | 270/240/160 | 150 | G3/4 |
 |
Basic 25-12S | 25 | 2 | 9.5 | 12 | 115/230 | 50/60 | 270/240/160 | 180 | G1 1/2 |
 |
Basic 20-12S | 20 | 2 | 9.5 | 12 | 115/230 | 50/60 | 270/240/160 | 150/180 | G1 |
 |
Basic 25-12 | 25 | 5 | 9 | 12 | 115/230 | 50/60 | 500 | 180/220 | G1 1/2 |
 |
Basic 25-9 | 25 | 5 | 5 | 9 | 115/230 | 50/60 | 300 | 180/220 | G1 1/2 |
 |
Basic 32-9F | 32 | 5 | 6.5 | 9 | 115/230 | 50/60 | 300 | 180/220 | G2 |
 |
Basic 32-9 | 32 | 5 | 6.5 | 9 | 115/230 | 50/60 | 300 | 180/220 | G2 |
 |
Basic 32-12 | 32 | 6 | 8 | 12 | 115/230 | 50/60 | 500 | 180 | G2/Flange |
 |
Basic 25-16 | 25 | 7 | 12.5 | 16 | 230 | 50/60 | 700 | 230 | G1 1/2 |
 |
Basic 32-16 | 32 | 7 | 12.5 | 16 | 230 | 50/60 | 700 | 230 | G2 |
 |
Basic 40-12F Pro | 40 | 8 | 10 | 14 | 220~240 | 50 | 700 | 250 | DN40 |
 |
Basic 25-20 | 25 | 9 | 14 | 20 | 230 | 50/60 | 1000 | 230 | G1 1/2 |
 |
Basic 32-20 | 32 | 9 | 14 | 20 | 230 | 50/60 | 1000 | 230 | G2 |
 |
Basic 40-16F Pro | 40 | 8 | 13.5 | 18 | 220~240 | 50 | 1000 | 250 | DN40 |
 |
Basic 50-12F Pro | 50 | 16 | 8 | 12 | 220~240 | 50 | 1000 | 280 | DN50 |
 |
Basic 80-8SF Pro | 80 | 25 | 5 | 8 | 380 | 50 | 1000 | 360 | Flange |
 |
Basic 25-16S | 25 | 7 | 12.5 | 16 | 380 | 50 | 700 | 230 | G1 1/2 |
 |
Basic 32-16S | 32 | 7 | 12.5 | 16 | 380 | 50 | 700 | 230 | G2 |
 |
Basic 40-12SF Pro | 40 | 8 | 10 | 12 | 230/380 | 50 | 700 | 250 | DN40 |
 |
Basic 65-8SF Pro | 65 | 20 | 4.2 | 8.4 | 380 | 50 | 700 | 340 | DN65 |
 |
Basic 25-20S | 25 | 9 | 14 | 20 | 380 | 50 | 1000 | 230 | G1 1/2 |
 |
Basic 32-20S | 32 | 9 | 14 | 20 | 380 | 50 | 1000 | 230 | G2 |
 |
Basic 40-16SF Pro | 40 | 8 | 15 | 18 | 230/380 | 50 | 1000 | 250 | DN40 |
 |
Basic 50-12SF Pro | 50 | 15 | 9 | 12 | 230/380 | 50 | 1000 | 280 | DN50 |
 |
Basic 80-10SF Pro | 80 | 25 | 8 | 10 | 380 | 50 | 1300 | 360 | DN80 |
 |
Basic 50-16SF Pro | 50 | 16 | 12 | 16 | 380 | 50 | 1300 | 280 | DN50 |
 |
Basic 50-20SF Pro | 50 | 16 | 13.7 | 20 | 380 | 50 | 1500 | 280 | DN50 |
 |
Basic 65-15SF Pro | 65 | 20 | 12 | 15 | 380 | 50 | 1500 | 340 | DN65 |
